xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
351
Figure 8-42 WAC Port Settings window
The fields that can be configured are described below:
Parameter Description
Select the unit you want to configure. (EI and SI Mode Only)
Use the drop-down menus to select a range of ports to be enabled as WAC ports.
Aging Time (1-1440)
Specify the time period during which an authenticated host will remain in the
authenticated state. Enter a value between 1and 1440 minutes. Tick the Infinite check
box to indicate the authenticated host will never age out on the port. The default value
is 1440 minutes (24 hours).
Use this drop-down menu to enable the configured ports as WAC ports.
Idle Time (1-1440)
If there is no traffic during the Idle Time parameter, the host will be moved back to the
unauthenticated state. Enter a value between 1 and 1440 minutes. Tick the Infinite
check box to indicate the Idle state of the authenticated host on the port will never be
checked. The default value is infinite.
Block Time (0-300)
This parameter is the period of time a host will be blocked if it fails to pass
authentication. Enter a value between 0 and 300 seconds. The default value is 60
Click the Apply button to accept the changes made.
WAC Authentication State
Users can view and delete the hosts for Web authentication.
To view this window, click Security > Web-based Access Control (WAC) > WAC Authentication State as
shown below:
