xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
157
Figure 4-117 LLDP Statistics System window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit you want to configure. (EI and SI Mode Only)
Port
Use the drop-down menu to select a port.
Click the Find button to locate a specific entry based on the information entered.
LLDP Local Port Information
This window displays the information on a per port basis currently available for populating outbound LLDP
advertisements in the local port brief table shown below.
To view the following window, click L2 Features > LLDP > LLDP > LLDP Local Port Information, as shown
below:
Figure 4-118 LLDP Local Port Information window
The fields that can be configured are described below:
