D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
220
Parameter Description
RIPng State
Click to enable or disable the RIPng state.
Method
Use the drop-down menu to select the method of RIPng.
No Horizon – Select for not using any horizon.
Split Horizon – Select to use basic split horizon.
Poison Reverse – Select to use poison-reverse.
Update Time (5-65535)
Specifies the update timer.
Expire Time (1-65535)
Specifies when to expire the update.
Garbage Collection
Time (1-65535)
Specifies the garbage-collection timer.
Click the Apply button to accept the changes made.
RIPng Interface Settings
This window is used to display and configure the RIPng interface settings.
To view the following window, click L3 Features > RIP > RIPng > RIPng Interface Settings, as shown below:
Figure 5-91 RIPng Interface Settings window
The fields that can be configured are described below:
Parameter Description
Interface Name
Enter the IPv6 interface name.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the configure entries.
Click the Edit button to re-configure the specific entry.
Click the Edit button to see the following window.
Figure 5-92 RIPng Interface Settings -Edit window
The fields that can be configured are described below:
Parameter Description
State
Select to enable or disable the RIPng state on the selected interfaces.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
