xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
345
Figure 8-35 MAC-based Access Control Port Settings window
The fields that can be configured are described below:
Parameter Description
Select the unit you want to configure. (EI and SI Mode Only)
From Port / To Port
Use the drop-down menus to select a range of ports to be configured for MAC-based
State
Use this drop-down menu to enable or disable MAC-based access control on the port
or range of ports selected in the Port Settings section of this window.
Toggle between Port-based and Host-based.
Aging Time (1-1440) Enter a value between 1 and 1440 minutes. The default is 1440. To set this value to
have no aging time, select the Infinite option.
Enter a value between 0 and 300 seconds. The default is 300.
Max User (1-1000) Enter the maximum user used for this configuration. When No Limit is selected, there
will be no user limit applied to this rule.
Click the Apply button to accept the changes made.
MAC-based Access Control Local Settings
Users can set a list of MAC addresses, along with their corresponding target VLAN, which will be authenticated for
the Switch. Once a queried MAC address is matched in this window, it will be placed in the VLAN associated with it
here. The Switch administrator may enter up to 128 MAC addresses to be authenticated using the local method
configured here.
To view this window, click Security > MAC-based Access Control (MAC) > MAC-based Access Control Local
Settings as shown below:
