xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
443
To view this window, click Monitoring > Utilization > DRAM & Flash Utilization as shown below:
Figure 11-2 DRAM & Flash Utilization window
The fields that can be configured are described below:
Parameter Description
Select the unit you want to configure. (EI and SI Mode Only)
Click the Apply button to accept the changes made.
Port Utilization
Users can display the percentage of the total available bandwidth being used on the port.
To view this window, click Monitoring > Utilization > Port Utilization as shown below:
Figure 11-3 Port Utilization window
The fields that can be configured are described below:
Parameter Description
Select the unit you want to configure. (EI and SI Mode Only)
Use the drop-down menu to choose the port that will display statistics.
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
