D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
168
Figure 5-10 IPv6 Route Table window (RI Mode Only)
Figure 5-11 IPv6 Route Table window (EI Mode Only)
Figure 5-12 IPv6 Route Table window (SI Mode Only)
The fields that can be configured are described below:
Parameter Description
IPv6 Address/Prefix
Length
Tick the check box and enter a 128-bit length IPv6 address. (RI and EI Mode
Only)
IPv6 Address
Tick the check box and enter the destination IPv6 address of the route to be
displayed. (RI and EI Mode Only)
RIPng
Tick the check box to display routes that are related to RIPng. (RI Mode Only)
OSPFv3
Tick the check box to display routes that are related to OSPFv3. (RI Mode Only)
Hardware
Tick the check box to display only the routes that have been written into the chip.
Click the Find button to locate a specific entry based on the information entered.
Policy Route Settings (RI Mode Only)

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
