xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
174
CRC High
Tick the check box so that the ECMP algorithm will include the upper 5 bits of the
CRC. This attribution is mutually exclusive with Source IP and CRC Low. If it is set,
Source IP and CRC Low will be excluded.
Tick the check box so that the ECMP algorithm will include the TCP or UDP port.
Click the Apply button to accept the changes made for each individual section.
Route Redistribution (RI Mode Only)
Route Redistribution Settings
This window is used to configure redistribute routing information from one routing protocols to another.
To view the following window, click L3 Features > Route Redistribution > Route Redistribution Settings, as
shown below:
Figure 5-22 Route Redistribution Settings window
The fields that can be configured are described below:
Parameter Description
Specifies the destination protocol. Options to choose from are RIP and OSPF.
Specifies the source protocol. Options to choose from are RIP, OSPF, Static and Local.
Type Specifies the type of route to be redistributed. Options to choose from are All, Internal,
External, Ext Type1, Ext Type2, Inter+E1, Inter+E2, Type-1, and Type-2. To redistribute
all types of route select the All option.
Metric
Specifies the metric value for the redistributed routes. Enter the value between 0 and
16 when the Destination Protocol is RIP. Enter the value between 0 and 16777214
when the Destination Protocol is OSPF.
Enter the route map name for the entry here.
Click the Apply button to accept the changes made.
Click the Edit button to re-configure the specified entry.
Click the Delete button to remove the specified entry.
IPv6 Route Redistribution Settings
This window is used to configure the IPv6 route redistribution settings.
To view the following window, click L3 Features > Route Redistribution > IPv6 Route Redistribution Settings,
as shown below:
