xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
145
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the Group List link to configure the multicast address group list settings for the specific entry.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
After clicking the Group List link, the following window will appear:
Figure 4-103 Multicast Address Group List Settings window
The fields that can be configured are described below:
Parameter Description
Display the profile name.
Enter the multicast address list here.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
IPv6 Limited Multicast Range Settings
Users can configure the ports and VLANs on the Switch that will be involved in the Limited IPv6 Multicast Range.
To view the following window, click L2 Features > Multicast Filtering > IPv6 Multicast Filtering > IPv6 Limited
Multicast Range Settings, as shown below:
Figure 4-104 IPv6 Limited Multicast Range Settings window
The fields that can be configured are described below:
Parameter Description
Select the appropriate port(s) or VLAN IDs used for the configuration here.
Assign access permissions to the ports selected. Options listed are Permit and Deny.
