xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
126
Click the Apply button to accept the changes made for each individual section.
Click the Select All button to select all the ports for configuration.
Click the Clear All button to unselect all the ports for configuration.
MLD Proxy Downstream Settings
Users can configure the MLD proxy downstream interface in this page. The MLD proxy downstream interface must
be a MLD snooping enabled VLAN.
To view the following window, click L2 Features > L2 Multicast Control > MLD Proxy > MLD Proxy
Downstream Settings, as shown below:
Figure 4-71 MLD Proxy Downstream Settings window
The fields that can be configured are described below:
Parameter Description
The VLAN name for the interface.
The VID List for the interface.
Downstream Action Here the user can select the appropriate action. Selecting Add will add a downstream
interface. Selecting Delete will remove a downstream interface.
Click the Apply button to accept the changes made.
MLD Proxy Group
This window is used to display the MLD Proxy Group.
To view the following window, click L2 Features > L2 Multicast Control > MLD Proxy > MLD Proxy Group, as
shown below:
Figure 4-72 MLD Proxy Group window
Click the Member Ports link to view the MLD proxy member port information.
After clicking the Member Ports option, the following window will appear.
Figure 4-73 MLD Proxy Group window
