D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
342
Figure 8-32 ND Snooping Maximum Entry Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit you want to configure. (EI Mode Only)
From Port / To Port
Use the drop-down menus to select a range of ports that require a restriction on the
maximum number of entries that can be learned with ND snooping.
Maximum Entry (1-50) Enter the maximum entry value. Tick the No Limit check box to have unlimited
maximum number of the learned entries.
Click the Apply button to accept the changes made.
ND Snooping Entry
This window is used to view dynamic entries on specific ports.
To view this window, click Security > IP-MAC-Port Binding (IMPB) > ND Snooping > ND Snooping Entry as
shown below:
Figure 8-33 ND Snooping Entry window
The fields that can be configured are described below:
Parameter Description

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
