DAF LF45 Series Service Manual

©
200508 5-1
Cleaning
PNEUMATIC GEARBOX CONTROL
ΛΦ45/55 series
3
3
5. CLEANING
5.1 CLEANING FILTER/GOVERNOR
Cleaning filter/governor
1. Remove the cover (5).
2. Remove the filter element (2) from the
housing (1).
3. Clean the filter element (2) with cold water
and soap, or replace if necessary.
4. Blow-clean the filter element (2) and the
housing (1) from the inside with compressed
air.
5. Replace the O-ring (4) and the sealing ring
(3), if necessary.
6. Fit the cover (5) and tighten it to the specified
torque. See "Technical data".
7. Pressurise the system.
8. Check the system for air leakage.
6
5
4
3
2
1
10
9
8
V300430
7
