DAF LF45 Series Service Manual

©
200508 4-1
ZF 6S-850 gearbox
TECHNICAL DATA
ΛΦ45/55 series
3
0
4. ZF 6S-850 GEARBOX
4.1 GENERAL
Gearbox type
Each gearbox has a type plate attached to it,
indicating the type of gearbox. This data can also
be found on the vehicle identity card for the
vehicle concerned.
ZF gearbox type plate
Output shaft bearing axial play
Bearing axial play, main and input shafts
Secondary shaft bearing axial play
V300049
1
2
4
5
3
8
6
7
10
9
1. Type of gearbox
2. Serial no. (ZF)
3. Parts list (ZF)
4. Specification no.
5. Pulse generator ratio
6. Gearbox ratio
7. Engine speed using PTO
8. PTO speed
9. Gearbox oil capacity
10. Oil specification
Output shaft bearing axial play 0.00 - 0.10 mm
Bearing axial play, main and input shafts 0.00 - 0.10 mm
Secondary shaft bearing axial play 0.00 - 0.10 mm
