200508 5-5
Removal and installation
CLUTCH
ΛΦ45/55 series
3
9
5.5 REMOVAL AND INSTALLATION, PILOT BEARING
Removing pilot bearing
1. Remove the gearbox.
2. Remove the clutch release assembly and the
clutch plate.
3. Use an internal puller (2) to remove the pilot
bearing (1) from the flywheel.
Fitting pilot bearing
1. Check the flywheel bore for dirt and damage.
Note:
The pilot bearing (1) has a grease and dust seal
(2) on one side only. When the pilot bearing is
installed, the grease and dust seal must be on the
clutch plate side.
W 3 04 016
1
2
W 3 04 019
1
2
DAF LF Gearboxes and Clutch Service Manual
