TECHNICAL DATA
6-2
©
200508
Allison 1000 & 2000 automatic gearboxes
0
ΛΦ45/55 series
3
6.2 TIGHTENING TORQUES
The tightening torques stated in this paragraph
are different from the standard tightening torques
stated in the overview of the standard tightening
torques.
The other threaded connections not specified
must therefore be tightened to the torque
mentioned in the overview of standard tightening
torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Gearbox
Flexplates
Selector switch
Speed sensor
Oil sump
PTO cover
Plugs
Hydraulic lines
Drive flange
Attachment bolts 60 Nm
Hydraulic pipes to oil cooler 25 Nm
Bolts attaching gearbox to flywheel housing 34 Nm
Flexplate adapter attachment bolts 64 Nm
Crankshaft attachment bolts 30 Nm + 60″ angular displacement
Attachment bolts 27 Nm
Attachment nut 24 Nm
Attachment bolt 12 Nm
Attachment bolts 27 Nm
Attachment bolts 43 Nm
Gearbox drain plug 35 Nm
Oil cooler drain plug 28 Nm
Oil cooler air bleed plug 28 Nm
Attachment to gearbox 25 Nm
Attachment bolt 122 Nm
DAF LF Gearboxes and Clutch Service Manual
