PNEUMATIC GEARBOX CONTROL
1-2
©
200508
General
3
ΛΦ45/55 series
3
1.2 PNEUMATIC DIAGRAM, GEARBOX CONTROL
N
V
1
1
21
GP
H
L
H
L
4
1
21
22
V3 00 359
45
6 2
1
3
+
1. VIC electronic unit
2. Electropneumatic downshift protection valve
3. Range group engaging cylinder
4. Neutral position valve
5. Filter/governor
6. Range group operating switch
L Position "low"
H Position "high"
N Gearbox selector shaft in neutral
V Gearbox selector shaft engaged
DAF LF Gearboxes and Clutch Service Manual
