200508 3-1
Inspection and adjustment
ZF S5-42 GEARBOX
ΛΦ45/55 series
3
4
3. INSPECTION AND ADJUSTMENT
3.1 CHECKING GEARBOX OIL LEVEL
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
1. Place the vehicle on a flat and level surface.
2. Wait for some minutes to allow the oil to flow
back.
3. Remove the level check/filler plug (2) and
check the oil level.
4. The oil level must reach the rim of the level
check/filler opening.
5. After checking the oil level, tighten the level
check plug to the specified torque. See
"Technical data".
}
21
V3 00 403
DAF LF Gearboxes and Clutch Service Manual
