200508 4-1
Removal and installation
ALLISON MD 3060 AUTOMATIC GEARBOX
ΛΦ45/55 series
3
8
4. REMOVAL AND INSTALLATION
4.1 REMOVAL AND INSTALLATION, GEARBOX ASSEMBLY
Removing gearbox assembly
1. Note:
Before the gearbox can be removed, the
gearbox oil must be drained.
2. If necessary, remove the oil filler pipe to
avoid damage.
3. Plug the external oil pipes after removing
and/or detaching them to prevent dirt
entering the oil system.
4. Disconnect the gearbox wiring harness
connectors and secure the wiring harness.
Plug the openings.
5. Remove the prop shaft.
6. See what is best for gearboxes with PTO:
remove the PTO from the gearbox,
disconnect the hydraulic pipes from the
pump or remove the prop shaft, if fitted.
7. Remove the gearbox from the engine.
DAF LF Gearboxes and Clutch Service Manual
