200508 3-1
Removal and installation
EATON FS/6309A GEARBOX
ΛΦ45/55 series
3
6
3. REMOVAL AND INSTALLATION
3.1 REMOVAL AND INSTALLATION, GEARBOX ASSEMBLY
Removing gearbox assembly
1. Disconnect the earth lead from the battery
terminal.
2. Remove the attachment bolts of the prop
shaft flange and remove the prop shaft.
3. Remove the attachment bolts from the
intermediate bearing.
4. Remove the attachment bolt from the
exhaust bracket on the gearbox.
5. Remove the clamping straps of the
intermediate pipe and remove it.
6. Remove the end of the exhaust by removing
the clamping strap and the attachment bolt of
the rubber suspension point at the end of the
exhaust.
7. Remove the attachment bolts from the clutch
cylinder and remove it.
8. Mark all the electrical connectors and
remove them.
9. Remove the compressor pipe bracket.
10. Mark the various air pipes and remove them.
11. Remove the selector rod from the adjusting
mechanism in such a manner that the
settings are not changed.
12. Support the gearbox and remove the
attachment bolts around it.
13. Manoeuvre the gearbox to the rear until it is
free, and then remove it.
