DAF LF45 Series Service Manual

MECHANICAL GEARBOX CONTROL
3-2
©
200508
Removal and installation
2
ΛΦ45/55 series
3
3.2 REMOVING AND INSTALLING GAITER
Removing gaiter
1. Remove the switch button.
2. Disconnect the underside of the gaiter.
3. Pull the gaiter over the switch button and
remove the clamping strap (1).
4. Remove the gaiter.
Installing gaiter
1. Fit a new clamping strap on the inside of the
gaiter.
2. Fit the top of the gaiter inside out over the
gear lever and tighten the clamping strap (1).
3. Pull the entire gaiter over the gear lever.
4. Tighten the underside of the gaiter.
V3 00 578
1
