200508 3-3
Inspection and adjustment
ALLISON MD 3060 AUTOMATIC GEARBOX
ΛΦ45/55 series
3
8
3.2 CHECKING OIL LEVEL WITH SELECTOR KEYPAD
Checking oil level with selector keypad
1. Place the vehicle on a flat and level surface
and apply the parking brake.
2. Put the gearbox in the neutral position and
bring the gearbox to operating temperature
(approx. 71″ - 93″C).
3. Run the engine at idling speed for 2 minutes.
4. Press both arrow keys on the selector
keypad simultaneously. The display now
shows the letters O and L.
Note:
O and L stand for Oil Level
5. When the oil level is correct, the letters O - K
appear on the display.
When the oil level is too high, this is indicated
by HI followed by the number of litres in
excess.
When the oil level is too low, this is indicated
by LO followed by the number of litres
lacking.
Example
LO-02 means that two litres have to be
added.
HI-03 means that three litres have to be
drained.
6. Press the N key to exit the system.
R
D
MODE
N
V300392
DAF LF Gearboxes and Clutch Service Manual
