Eaton FS/6309A gearbox
0
ΛΦ45/55 series
3
5.2 TIGHTENING TORQUES
The tightening torques stated in this paragraph
are different from the standard tightening torques
stated in the overview of the standard tightening
torques.
The other threaded connections not specified
must therefore be tightened to the torque
mentioned in the overview of standard tightening
torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Gearbox
Drive flange
Gearbox front cover
Selector shaft housing
Filter/governor
Plugs
(1) Use new nut
(2) Use Loctite 243
Attachment bolts 60 Nm
M39 attachment nut 650 Nm
(1)
Drive flange oil seal housing attachment bolts 37 Nm
Attachment bolts 37 Nm
Selector shaft housing attachment bolts 37 Nm
(2)
M8 retaining cover attachment bolts 22 Nm
M8 shifting arm lock nut 25 Nm
M10 shifting arm lock nut 37 Nm
End cover attachment bolts 22 Nm
Bleeder 19 Nm
Bleed valve 22 Nm
M6 attachment bolts 13 Nm
Cover 25 Nm
Oil level check/filler plug 35 Nm
Drain plug 44 Nm
DAF LF Gearboxes and Clutch Service Manual
