EATON FS/6309A GEARBOX
3-4
©
200508
Removal and installation
6
ΛΦ45/55 series
3
3.3 REMOVAL AND INSTALLATION, OUTPUT SHAFT OIL SEAL
Removing output shaft oil seal
1. Remove the drive flange.
2. Remove the attachment bolts from the oil
seal housing. Remove the oil seal housing.
Remove the oil seal.
3. Clean the contact surfaces of the oil seal and
the seal housing.
Installing output shaft oil seal
1. Press the oil seal into the oil seal housing
using special tool (DAF no. 1329358).
2. Apply sealant to the contact surface of the
seal housing. See "Technical data".
3. Fit the seal housing and tighten the bolts to
the specified torque. See "Technical data".
4. Apply grease to the sealing lip of the oil seal.
5. Fit the drive flange.
6. If necessary, top up the gearbox. See
"Inspection and adjustment".
DAF LF Gearboxes and Clutch Service Manual
