TECHNICAL DATA
2-2
©
200508
Pneumatic gearbox control
0
ΛΦ45/55 series
3
2.2 TIGHTENING TORQUES
The tightening torques stated in this paragraph
are different from the standard tightening torques
stated in the overview of the standard tightening
torques.
The other threaded connections not specified
must therefore be tightened to the torque
mentioned in the overview of standard tightening
torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Filter/governor
Selector valve single-H
Range-change cylinder
Bleed valve
Eaton switch button
(1) Use Loctite 243
M6 attachment bolts 13 Nm
Cover 25 Nm
M6 attachment bolts 22 Nm
M16 discharge valve attachment bolts 19 Nm
M8 cover plate attachment bolts 22 Nm
M8 cover attachment bolts 17 Nm
M16 nut on piston 105 Nm
Attachment 19 Nm
Attachment nut 70 Nm
(1)
DAF LF Gearboxes and Clutch Service Manual
