ZF S5-42 GEARBOX
3-2
©
200508
Inspection and adjustment
4
ΛΦ45/55 series
3
3.2 INSPECTING AND ADJUSTING INPUT SHAFT PRE-LOAD
Inspecting and adjusting input shaft pre-load
1. Remove the gearbox. See "Removal and
installation".
2. Remove the gearbox front cover from the
input shaft. See "Removal and installation".
3. Uniformly press the outer bearing race (4),
so that the bearing is free of play. Constantly
rotate the input shaft while applying pressure
so that the bearing is set.
V3 00 413
1 3
5687
42
DAF LF Gearboxes and Clutch Service Manual
