Pneumatic gearbox control
DIAGNOSTICS
ΛΦ45/55 series
3
1
2. PNEUMATIC GEARBOX CONTROL
2.1 FAULT-FINDING TABLE
COMPLAINT: NOT POSSIBLE TO ENGAGE HIGH OR LOW RANGE
Possible cause Remedy
Air pressure too low Check air supply of circuit 4
Neutral position valve defective or incorrectly
connected
Connect valve properly or replace
Faulty downshift protection valve Replace valve
Defective high/low range engaging cylinder Check cylinder and replace if necessary
COMPLAINT: HIGH/LOW RANGE ENGAGING CYLINDER ENGAGES LOW AT TOO HIGH A
SPEED
Possible cause Remedy
Incorrect VIC frequency value Adjust value
COMPLAINT: HIGH OR LOW RANGE ENGAGING IS SLOW
Possible cause Remedy
Air pressure too low Check air supply of circuit 4
Piping blocked Check piping and clean, if necessary
Defective neutral position valve Replace valve
COMPLAINT: HIGH/LOW RANGE ENGAGING CYLINDER WORKS THE WRONG WAY ROUND
Possible cause Remedy
Air pipes on the high/low range engaging cylinder
are incorrectly connected
Connect engaging cylinder air pipes correctly
COMPLAINT: NOT POSSIBLE TO ENGAGE LOW RANGE
Possible cause Remedy
VIC defective Check VIC and replace, if necessary
Incorrect vehicle speed signal Check vehicle speed signal
