200508 3-3
Removal and installation
MECHANICAL GEARBOX CONTROL
ΛΦ45/55 series
3
2
3.3 REMOVING AND INSTALLING GEAR LEVER UNIT
Removing gear lever unit
1. Remove the switch button.
2. Remove the gaiter.
3. Remove the retainer clip from the telescopic
control rod underneath the cab and remove
the gear lever unit.
4. Remove the attachment bolts of the gear
lever on the bottom of the cab.
Installing gear lever unit
1. Slide the gear lever unit and the telescopic
control rod onto the gearbox control and fit
the retainer clip.
2. Install the gear lever in the cab via the feed-
through.
3. Fit the gear lever attachment bolts and
tighten them to the specified torque. See
"Technical data".
4. Fit the gaiter.
5. Fit the switch button.
6. Check that the operating mechanism does
not touch any vehicle parts during shifting.
DAF LF Gearboxes and Clutch Service Manual
