ALLISON 1000 & 2000 AUTOMATIC GEARBOXES
4-8
©
200508
Removal and installation
7
ΛΦ45/55 series
3
4.5 REMOVING AND INSTALLING OIL FILTERS
Removing oil filters
1. Clean the oil filters (1) and (5) and the
surrounding area.
2. Loosen the oil filters on the gearbox and the
heat exchanger.
3. Remove the magnetic rings (2) and (4) and
check them for wear particles.
Note:
If there are large wear particles in the wear
swarf, this indicates excessive wear in the
gearbox and the cause must be ascertained.
4. Clean the magnetic rings and the contact
surfaces on the gearbox housing and the
heat exchanger.
Installing oil filters
1. Fit the magnetic rings (2) and (4) on the
gearbox housing and the heat exchanger.
2. Lightly lubricate the new oil filters (1) and (5)
with clean gearbox oil and place the oil filters
on the gearbox and heat exchanger.
3. Tighten the oil filters until they touch the
contact surface. Manually tighten the oil
filters another 360″.
4. Check the oil level. See "Inspection and
adjustment".
1
2
V3 00 480
5
4
6
3
V3 00 556
DAF LF Gearboxes and Clutch Service Manual
