TECHNICAL DATA
3-2
©
200508
ZF S5-42 gearbox
0
ΛΦ45/55 series
3
3.2 TIGHTENING TORQUES
The tightening torques stated in this paragraph
are different from the standard tightening torques
stated in the overview of the standard tightening
torques.
The other threaded connections not specified
must therefore be tightened to the torque
mentioned in the overview of standard tightening
torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Gearbox
Drive flange
Gearbox front cover
Selector shaft housing
Plugs
(1) Fit new nut and apply Loctite 270 to it
(2) Fit new nut and apply Loctite 262 to it
Attachment bolts 60 Nm
'Direct drive' attachment nut 400 Nm
(1)
Overdrive attachment nut 330 Nm
(2)
Attachment bolts 23 Nm
Selector shaft housing attachment bolts 23 Nm
Shifting arm lock nut 46 Nm
Gearbox control attachment nut 52 Nm
Bleeder 10 Nm
Oil level check/filler plug 50 Nm
Drain plug 50 Nm
DAF LF Gearboxes and Clutch Service Manual
