ZF 6S-850 GEARBOX
4-6
©
200508
Removal and installation
5
ΛΦ45/55 series
3
4.4 REMOVAL AND INSTALLATION, OUTPUT SHAFT OIL SEAL
Removing output shaft oil seal
1. Remove the drive flange.
2. Pull the oil seal from the gearbox housing
using special tool (DAF no. 0484899).
Installing output shaft oil seal
1. Check the axial play of the output shaft. See
"Technical data".
2. Around the oil seal, clean the gearbox
housing without letting dirt into the gearbox.
3. Apply a small amount of liquid gasket to the
outside of oil seals fitted with a steel cover.
Apply a small amount of green soap to the
outside of oil seals fitted with a rubber cover.
4. Fit the oil seal in the gearbox housing using
special tool (DAF no. 0694816). The tool will
position the oil seal at the correct depth in the
housing.
5. Fit the drive flange.
W 3 03 048
7 mm
DAF LF Gearboxes and Clutch Service Manual
