200508 4-1
Removal and installation
ALLISON 1000 & 2000 AUTOMATIC GEARBOXES
ΛΦ45/55 series
3
7
4. REMOVAL AND INSTALLATION
4.1 REMOVING AND INSTALLING ENTIRE GEARBOX
Removing gearbox assembly
1. Drain the gearbox. See "Draining and filling".
2. If necessary, remove the oil filler pipe to
avoid damage.
3. Remove the oil pipes from and to the oil
cooler.
4. Plug the external oil pipes after removing
and/or detaching them to prevent dirt
entering the oil system.
5. Disconnect the gearbox wiring harness
connectors and secure the wiring harness.
Plug the openings.
6. Remove the selector cable.
7. Remove the prop shaft.
8. See what is best for gearboxes with PTO:
remove the PTO from the gearbox,
disconnect the hydraulic pipes from the
pump or remove the prop shaft, if fitted.
9. Remove the gearbox from the engine.
