200508 1-5
General
MECHANICAL GEARBOX CONTROL
ΛΦ45/55 series
3
2
1.5 OVERVIEW DRAWING, ZF GEARBOX GEAR LEVER
V3 00 569
1
2
3
1. Switch button
2. Gear lever
3. Bearing housing
DAF LF Gearboxes and Clutch Service Manual
