MECHANICAL GEARBOX CONTROL
1-2
©
200508
General
2
ΛΦ45/55 series
3
1.2 OVERVIEW DRAWING, OPERATING MECHANISM, 2 ADJUSTMENT
OPTIONS
V3 00 567
1
2
3
4
1. Control rod
2. Torque rod
3. Gearbox lever
4. Ball joint
DAF LF Gearboxes and Clutch Service Manual
