Removal and installation
EATON FS/6309A GEARBOX
ΛΦ45/55 series
3
6
3.2 REMOVAL AND INSTALLATION, DRIVE FLANGE
Removing drive flange
1. Place a reference mark on the prop shaft in
relation to the flange.
2. Remove the bolts that attach the prop shaft
to the flange.
3. Support the prop shaft from a suitable
location on the chassis.
4. Support the prop shaft from a suitable
location on the chassis.
5. Fit special tool (DAF no. 0484977) to hold
the flange in place. Remove the lock nut and
washer.
6. Remove the flange with a suitable puller.
Note:
In order to prevent the synchroniser for the
high/low transmission ratios from coming
loose, the output shaft must not slide out of
the bearing.
Installing drive flange
1. Place the flange on the output shaft.
2. Place a shim between the flange and the lock
nut and turn the flange in the oil seal.
Remove the lock nut and shim.
3. Fit special tool (DAF no. 0484977) to the
flange. Fit a new lock nut. Tighten the lock
nut to the specified torque. See "Technical
data".
4. Align the markings. Fit the prop shaft onto
the flange. Tighten the bolts to the specified
torque. See "Technical data".
DAF LF Gearboxes and Clutch Service Manual
