MECHANICAL GEARBOX CONTROL
1-6
©
200508
General
2
ΛΦ45/55 series
3
1.6 OVERVIEW DRAWING, EATON GEAR LEVER
V3 00 572
1
2
3
4
5
6
7
8
1. Cover plate
2. Attachment nut
3. O-ring
4. Switch button
5. Range group operating switch
6. Clamping plate
7. Gear lever
8. Bearing housing
