200508 3-1
Removal and installation
MECHANICAL GEARBOX CONTROL
ΛΦ45/55 series
3
2
3. REMOVAL AND INSTALLATION
3.1 REMOVING AND INSTALLING SWITCH BUTTON
Removing ZF gearbox switch button
1. Turn the switch button anti-clockwise away
from the gear lever.
Installing ZF gearbox gear lever
1. Apply locking compound to the gear lever
wire. See "Technical data".
2. Turn the switch button clockwise onto the
gear lever.
3. Position the switch button so that it
corresponds to the gear-shift movement.
Removing Eaton gearbox switch button
1. Remove the cover plate and the gear-
change pattern from the top of the switch
button.
2. Remove the attachment nut from the switch
button.
3. Remove the switch button.
4. Remove the gaiter.
5. Position the gear lever as far forward as
possible and remove the range-change
switch.
Installing Eaton gearbox switch button
1. Position the gear lever as far forward as
possible and fit the range-change switch
over the gear lever.
2. Position the air pipes so that they cannot get
trapped between the gear lever and the cab.
3. Fit the gaiter.
4. Apply locking compound to the gear lever
wire. See "Technical data".
5. Fit the switch button onto the gear lever and
tighten the attachment nut to the specified
torque. See "Technical data".
6. Fit the cover plate.
