MECHANICAL GEARBOX CONTROL
3-6
©
200508
Removal and installation
2
ΛΦ45/55 series
3
3.5 REMOVING AND INSTALLING REAR CONTROL ROD
Removing control rod behind the cab
1. Remove the attachment nut from the ball
joint (2).
2. Remove the attachment nut from torque rods
(1) and (4).
3. Remove the lock nut from the ball joint (5).
Note:
Make sure that the rearmost lock nut on the
ball joint (5) is not moved.
4. Remove the control rod (3).
V3 00 574
5
1
2
34
DAF LF Gearboxes and Clutch Service Manual
