ZF S5-42 GEARBOX
4-4
©
200508
Removal and installation
4
ΛΦ45/55 series
3
4.3 REMOVING AND INSTALLING OUTPUT SHAFT OIL SEAL
Removing output shaft oil seal
1. Remove the drive flange.
2. Prise the seal (2) out of the rear housing of
the gearbox.
Installing output shaft oil seal
1. Using special tool (DAF no. 0694816) (1), fit
the new seal in the rear housing.
2. Fit the drive flange.
V301012
2
1
DAF LF Gearboxes and Clutch Service Manual
