200508 4-3
Removal and installation
ALLISON MD 3060 AUTOMATIC GEARBOX
ΛΦ45/55 series
3
8
4.2 REMOVING AND INSTALLING OUTPUT SHAFT OIL SEAL
Removing output shaft oil seal
1. Remove the prop shaft and secure it so that
it does not interfere with further operations.
2. Unscrew the attachment bolt (5) of the flange
without removing it from the locking plate.
3. Remove the bolt and locking plate from the
flange.
Pay attention to the sealing rings on the outer
circumference and on the inside of the
locking plate.
W 3 03 061
V300529
1
2
3
5
4
V300559
DAF LF Gearboxes and Clutch Service Manual
