200508 2-3
Description of components
ALLISON MD 3060 AUTOMATIC GEARBOX
ΛΦ45/55 series
3
8
Faults
If the oil level indicator cannot give the correct oil
level, one of the following codes will appear in the
display.
The oil level reading function can be left by
pressing "D", "N", or "R".
Note: the function cannot be left by pressing the
arrow keys again, as this prompts the diagnostic
code reading function. All diagnostic codes are
preceded by the letter D followed by a number
between 1 and 5. In this function, important fault
codes could be deleted from the memory by an
unqualified user.
OL - 50 Engine speed too low
OL - 59 Engine speed too high
OL - 65 Gearbox is not in neutral
OL - 70 Gearbox oil temperature too low
OL - 79 Gearbox oil temperature too high
OL - 89 Output shaft is not stationary
(handbrake)
OL - 95 Oil level indicator is defective
DAF LF Gearboxes and Clutch Service Manual
