200508 4-3
Inspection and adjustment
CLUTCH
ΛΦ45/55 series
3
9
Note:
While releasing the clutch pedal, the clutch servo
should bleed itself via this bleed vent.
4. Depress the clutch pedal and check that
there is no leakage via the clutch servo bleed
vent.
5. Check that there is no oil leakage via the vent
opening (10).
Note:
A drop of oil on the vent opening (10) is normal
and is not a reason to replace the clutch servo.
If there is constant leakage, the clutch servo must
be repaired or replaced.
If in doubt as to whether the clutch servo situation
is normal or whether there is a leak, inspect the
fluid level in the clutch reservoir.
6. Depress the clutch pedal and check whether
there is an air leak via the vent opening (10).
DAF LF Gearboxes and Clutch Service Manual
