CLUTCH
5-8
©
200508
Removal and installation
9
ΛΦ45/55 series
3
2. Fit the fastening bridge (1) and tighten the
attachment screw.
3. Clip the plastic fastening jig (1) around the
clutch cylinder push rod and fit the switch
control (2) over the jig.
4. Screw the plastic fastening jig (1) into the
pedal.
5. Fit the spring (2) if it has been removed.
6. Fill the clutch system; see "Draining and
filling".
2
1
V3 00 577
21
V3 00 576
2
1
V3 00 579
DAF LF Gearboxes and Clutch Service Manual
