200508 2-5
Inspection and adjustment
MECHANICAL GEARBOX CONTROL
ΛΦ45/55 series
3
2
10. Loosen the lock nuts (3) of the gearbox lever.
11. Loosen the lock nuts (2) of the torque rod on
both sides.
12. Remove attachment nut (1) from the torque
rod on control rod side.
13. Fix the gear lever by fitting the special tool
(DAF no. 1329488) over the gear lever and
inserting the end of the gear lever through
the appropriate opening.
14. Fit the special tool (DAF no. 1453143)
between the ball joint (1) and the arm (2).
Centre the ball joint (1) by pressing it against
the shoulder of the special tool (A).
Note:
On the special tool (A) (DAF no. 1453143) it
is shown which side of the tool must be used
for LHD vehicles and which side for RHD
vehicles.
21
3
V3 00 575
V3 00 580
V3 00 840
RHD
1
A
2
DAF LF Gearboxes and Clutch Service Manual
