Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
1-53 Model S h ift Frequency
Range:
4.0 - 5 0.0 Hz
*
6.7 Hz
Function:
Flux Model shift
Enter the frequency value for shift between two
models for determining motor speed. Choose the
value based on se ttings in pa r. 1-00 Configuration
Mode and par. 1-01 Motor Control Principle.
There are two options: shift between Flux m od el
1 and Flux model 2; or shift between Variable
Current mode and Flux model 2. This parameter
is available for FC 302 only.
This parameter cannot be adjusted while
the motor is running.
FluxModel1–Fluxmodel2
Thismodelisusedwhenpar. 1-00issettoSpeed
closed loop [1] or Torque [2] and par. 1-01 is set to
Flux w/motor fe ed back [3]. With this parameter it
is possible to ma ke an adjustme nt of the shifting
point where FC 302 changes between Flux model 1
and Flux model 2, which is useful in some sensitive
speed and torque control applications.
Par. 1-00=[1]Speedclosedloopor[2]Torque
and par. 1 -01 = [3] Flux w/motor feedback
Variable C urrent - Flux model - Sensorless
Thismodelisusedwhenpar. 1-00isse
t
to Speed open loop [0] and par. 1-01 is
set to Flux sensorless [2].
In speed open loop in flux mode, the s
peed is
determined from the current measurement.
Below f
norm
x 0.1, the drive runs on a Va riable
Current model. Above f
norm
x0.1
25 the frequency
converter runs on a Flux model.
Par. 1-00 = [0] Speed open loop
Par. 1-01 = [2] Flux sensorless
1-55 U/f Characteristic - U
Range:
0.0 - max. motor voltage
*
Expression limit V
Function:
Enter the voltage at each frequency point to manually
form a U /f-characteristic m atching the motor.
Thefrequencypointsaredefinedinpar.
1-56 U/f Characteristic - F.
This parameter is a n array parameter [0-5]
and is only accessible when par. 1-01 Motor
Control Principle is set to U/f [0].
1-56 U/f Characteristic - F
Range:
0.0 - max. motor frequency
*
Expression lim it Hz
Function:
Enter the frequency points to manually form a
U/f-characteristic matching the motor.
The voltage at each point is defined in pa r.
1-55 U/f Characteristic - U.
This parameter is a n array parameter [0-5]
and is only accessible when par. 1-01 Motor
Control Principle is set to U/f [0].
*
default setting ()display text []value for use in communication via serial communication port
165
MG.33.B
6.22 - V LT is a registered Danfoss trademark
