Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
Out of speed range [10]
Below speed low [11]
Above speed high [12]
Out of feedb. range [13]
Below feedb. low [14]
Above feedb. high [15]
Thermal warning [16]
Line voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lo ck) [21]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26]
Logic rule 1 [27]
Logic rule 2 [28]
Logic rule 3 [29]
Timeout 0 [30]
Timeout 1 [31]
Timeout 2 [32]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Start command [39]
Drive stopped [40]
Function:
Select the first Boole an (TRUE or FALSE) input
for the selected logic rule.
*False [0] (default setting) enters the fixed
value of FALSE in the logic rule.
True [1] enters t he fixed value
TRUE in the logic rule.
Running [2] See parameter group 5-3*
for further description.
In rang e [3] See parameter gr
oup 5-3*
for further description.
On reference [4] See parameter group 5-3*
for further description.
Torque lim it [5] See parameter group 5-3*
for further description.
Current limit [6] See para
meter group 5-3*
for further description.
Out of current ra nge [7 ] See parameter group
5-3* for further descrip
tion.
Below I low [8] See parameter group 5 -3*
for further description.
Above I high [9] S ee parameter group 5-3*
for further description.
Out of speed range [10] See parameter group
5-3* for further description.
Below frequency low [11] See parameter group
5-3* for further description.
Above frequency high [12] See parameter group
5-3* for further description.
Out of feedback range [13] See parameter
group 5 -3* for further description.
Below feedback low [14] See parameter group
5-3* for further description.
Above feedback high [15] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group
5-3* for further description.
Line voltage out of range [17] See parameter
group 5 -3* for further description.
Reversing [18] Se e p arameter group 5-3*
for further description.
Warning [19] See pa rameter group 5-3*
for further description.
Alarm (trip) [20] See parameter group 5-3*
for further description.
Alarm (trip lock) [21] See parameter group
5-3* for further description.
Comparator 0 [22] Use the result of comparator
0 in the logic rule.
Comparator 1 [23] Use the result of comparator
1 in the logic rule.
Comparator 2 [24] Use the result of comparator
2 in the logic rule.
Comparator 3 [25] Use the result of comparator
3 in the logic rule.
Logic rule 0 [26] Use the result of logic
rule 0 i n the logic rule.
Logic rule 1 [27] Use the result of logic
rule 1 i n the logic rule.
Logic rule 2 [28] Use the result of logic
rule 2 i n the logic rule.
Logic rule 3 [29] Use the result of logic
rule 3 i n the logic rule.
Timeout 0 [30] Use the result of timer
0 in the logic rule.
Timeout 1 [31] Use the result of timer
1 in the logic rule.
*
default setting ()display text []value for use in communication via serial communication port
230
MG.33.B
6.22 - V LT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
