Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
Timeout 2 [32] Use the result of timer
2 in the logic rule.
Digital input DI18 [33] Use the value of DI18
in the logic rule (High = TRUE).
Digital input DI19 [34] Use the value of DI19
in the logic rule (High = TRUE).
Digital input DI27 [35] Use the value of DI27
in the logic rule (High = TRUE).
Digital input DI29 [36] Use the value of DI29
in the logic rule (High = TRUE).
Digital input DI32 [37] Use the value of DI32
in the logic rule (High = TRUE).
Digital input DI33 [38] Use the value of DI33
in the logic rule (High = TRUE).
13-41 Logic R ule Operator 1
Array [4]
Option:
*
Disabled [0]
And [1]
Or [2]
And not [3]
Or not [4]
Not and [5]
Not or [6]
Not and not [7]
Not or not [8]
Function:
Select the first logical operator to use on the
Boolean inputs from par. 13-40 and 13-42.
[13 -XX] signifies the boolean input of par. 13-*.
Select DISABLED [0 ] to ignore par. 1 3-42,
13-43, and 13-44.
AND [1] evaluates the expression [13-
40] AND [13-42].
OR [2] evaluates the expression [13-40] OR [13-42].
AND NOT [3] evaluates the expression
[13-40] AN D NOT [13 -42].
OR NOT [4] evaluates the expression [13-40]
OR NOT [13-42].
NOT AND [5 ] evaluates the expression NOT
[13-40] AND [13-42].
NOT OR [6] evaluates the expression N OT
[13-40] OR [13-42].
NOT AND NOT [7] evaluates the expression
NOT [1 3-40] AND NOT [13-42].
NOT OR NOT [8] evaluates the expression
NOT [13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Array [4]
Option:
*Fals e [0]
True [1]
Running [2]
In range [3]
On reference [4]
Tor q ue l imi t [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Out of speed range [10]
Below speed low [11]
Above speed high [12]
Out of feedb. range [13]
Below feedb. low [14]
Above feedb. high [15]
Thermal warning [16]
Line voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lock) [21]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26 ]
Logic rule 1 [27 ]
Logic rule 2 [28 ]
Logic rule 3 [29 ]
Timeout 0 [30]
Timeout 1 [31]
Timeout 2 [32]
Digital input DI18 [33 ]
Digital input DI19 [34 ]
Digital input DI27 [35 ]
Digital input DI29 [36 ]
Digital input DI32 [37 ]
Digital input DI33 [38 ]
Start command [39]
Drive sto pped [40 ]
*
default setting ()display text []value for use in communication via serial communication port
231
MG.33.B
6.22 - V LT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
