Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
Function:
Select the second Boolean (TRUE or FALSE)
input for the selected logic rule. See par.
13-40 for further explanation.
13-43 Logic R ule Operator 2
Array [4]
Option:
*
Disabled [0]
And [1]
Or [2]
And not [3]
Or not [4]
Not and [5]
Not or [6]
Not and not [7]
Not or not [8]
Function:
Select the second logical operator to be used
on the boolean input calculated in par. 13-40,
13-41, and 13-42, and the boolean input
coming from par. 13-42.
[13-44] signifies the boole an input of par. 13-44.
[13-40/13-42] signifies the boolean input
calculated in par. 13-40, 13-41, and 13-42.
DISABLED [0] (factory setting) . select this
option to ignore par. 13-44.
AND [1] evaluates the expression [13-
40/13-42] AND [13-44].
OR [2] evaluates the expression [13-40/ 13-
42] OR [13-44].
AND NOT [3] evaluates the expression
[13-40/13-42] A ND NOT [13-44].
OR NOT [4] evaluates the expression
[13-40/13-42] OR NOT [13-44].
NOT AND [5 ] evaluates the expression NOT
[13-40/13-42] A ND [13-44].
NOT OR [6] evaluates the expression N OT
[13-40/13-42] OR [13-44].
NOT AND NOT [7] evaluates the expression NOT
[13-40/13-42] and evaluates AND NOT [13-44].
NOT OR NOT [8] evaluates the e xpression NOT
[13-40/13-42] OR NOT [13-44].
13-44 Logic Ru le Boolean 3
Array [4]
Option:
*Fals e [0]
True [1]
Running [2]
In range [3]
On reference [4]
Tor q ue l imi t [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Out of speed range [10]
Below speed low [11]
Above speed high [12]
Out of feedb. range [13]
Below feedb. low [14]
Above feedb. high [15]
Thermal warning [16]
Line voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lock) [21]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26 ]
Logic rule 1 [27 ]
Logic rule 2 [28 ]
Logic rule 3 [29 ]
Timeout 0 [30]
Timeout 1 [31]
Timeout 2 [32]
Digital input DI18 [33 ]
Digital input DI19 [34 ]
Digital input DI27 [35 ]
Digital input DI29 [36 ]
Digital input DI32 [37 ]
Digital input DI33 [38 ]
Start command [39]
Drive sto pped [40 ]
Function:
Select the third Boolean (TRUE or FALSE) input
for the selected logic rule.
" 13-5* States
Parameters fo
r Programming the Smart
Logic Controller.
*
default setting ()display text []value for use in communication via serial communication port
232
MG.33.B
6.22 - V LT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
