FC 300 Design Guide
How to Program
13-51 SL Controller Event
Array [20]
Option:
*
False [0]
True [1]
Running [2]
In range [3]
On reference [4]
Torque limit [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Out of speed range [10]
Below s
peed low
[11]
Above speed high [12]
Out of feedb. range [13]
Be
low feedb. low
[1
4]
Above feedb. high [15]
Thermal warning [16]
Line voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lo ck) [21]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26]
Logic rule 1 [27]
Logic rule 2 [28]
Logic rule 3 [29]
Timeout 0 [30]
Timeout 1 [31]
Timeout 2 [32]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Start command [39]
Drive stopped [40]
Function:
Select the boolean input (TRUE or FALSE) to
define the smart logic controller event.
*False [0] enters the fixed value FALSE in t he event.
True [1] enters the fixed value TRUE in the event.
Running [2] See parameter group 5-3*
for further description.
In range [3] See parameter group 5-3*
for further description.
On reference [4] See parameter group 5-3*
for further description.
Torque limit [5] See parameter group 5-3*
for further description.
Current limit [6] See parameter group 5-3*
for further description.
Out of current range [7] See parameter group
5-3* for further description.
Above I low [8] See parameter group 5-3*
for further description.
Below I high [9] Se e parameter group 5-3*
for further description.
Out of speed range [10] See parameter group
5-3* for further description.
Above frequency low [11] See parameter group
5-3* for further description.
Below frequency high [12] See parameter group
5-3* for further description.
Out of feedback range [13] See parameter
group 5 -3* for further description.
Below feedback low [14] See parameter group
5-3* for further description.
Above feedback high [15] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group
5-3* for further description.
Line voltage out of range [17] See parameter
group 5 -3* for further description.
Reversing [18] Se e p arameter group 5-3*
for further description.
Warning [19] See pa rameter group 5-3*
for further description.
Alarm (trip) [20] See parameter group 5-3*
for further description.
Alarm (trip lock) [21] See parameter group
5-3* for further description.
Comparator 0 [22] Use the result of
comparator 0 in the event.
Comparator 1 [23] Use the result of
comparator 1 in the event.
Comparator 2 [24] Use the result of
comparator 2 in the event.
Comparator 3 [25] Use the result of
comparator 3 in the event.
*
default setting ()display text []value for use in communication via serial communication port
233
MG.33.B
6.22 - V LT is a registered Danfoss trademark
