FC 300 Design Guide
How to Program
Logic rule 0 [26] Use the result of logic
rule 0 in the event.
Logic rule 1 [27] Use the result of logic
rule 1 in the event.
Logic rule 2 [28] Use the result of logic
rule 2 in the event.
Logic rule 3 [29] Use the result of logic
rule 3 in the event.
Timeout 0 [30] Use the result of timer 0 in the event.
Timeout 1 [31] Use the result of timer 1 in the event.
Timeout 2 [32] Use the result of timer 2 in the event.
Digital input DI18 [33] Use the value of DI18
in the event (High = TRUE).
Digital input DI19 [34] Use the value of DI19
in the event (High = TRUE).
Digital input DI27 [35] Use the value of DI27
in the event (High = TRUE).
Digital input DI29 [36] Use the value of DI29
in the event (High = TRUE).
Digital input DI32 [37] Use the value of DI32
in the event (High = TRUE).
Digital input DI33 [38] Use the value of DI33
in the event (High = TRUE).
Start command [39] This event is TRUE if
theadjustablefrequencydriveisstartedby
any means (either via digital input, serial
communication bus or other).
Drive stopped [40] This event is TRUE if
theadjustablefrequencydriveisstoppedor
coasted by any means (either via digit al input,
ser. com. bus or other).
13-52 SL Controller Action
Array [20]
Option:
*
Disabled [0]
No action [1]
Select se
t-up 0
[2]
Select set-up 1 [3]
Select set-up 2 [4]
Selec
tset-up3
[5]
Select preset ref. 0 [10]
Select preset ref. 1 [11]
Sel
ectpresetref. 2
[12
]
Select preset ref. 3 [13]
Select preset ref. 4 [14]
Select preset ref. 5 [15]
Select preset ref. 6 [16]
Select preset ref. 7 [17]
Select ramp 1 [18]
Select ramp 2 [19 ]
Select ramp 3 [20 ]
Select ramp 4 [21 ]
Run [22]
Run reverse [23]
Stop [24]
Qstop [25]
Dcstop [26]
Coast [27]
Freeze outp ut [28]
Start timer 0 [29]
Start timer 1 [30]
Start timer 2 [31]
Setdig.out.Alow [32]
Setdig.out.Blow [33]
Setdig.out.Clow [34]
Setdig.out.Dlow [35]
Set dig. out. E low [36]
Set dig. out. F low [ 37]
Set dig. out. A high [38]
Set dig. out. B high [39]
Set dig. out. C high [40]
Setdig.out.Dhigh [41]
Set dig. out. E high [42]
Setdig.out.Fhigh [43]
Reset Counter A [60]
Reset Counter B [61]
Function:
Select the ac tion corresponding to the SLC event.
Actions are executed when the corre s
ponding event
(defined in par. 13-51) is evaluated as true. The
following actions are available for selection:
*DISABLED [0]
No action [1]
Select set-up 1 [2] - changes the active
set-up (par. 0-1 0) to ‘1’.
Select set-up 2 [3] - changes the active
set-up (par. 0-1 0) to ‘2’.
Select set-up 3 [4] - changes th
eactive
set-up (par. 0-1 0) to ‘3’.
Select set-up 4 [5] - changes the active setup (par.
0-10) to ‘4’. If the set-up is c
hanged, it will merge
with other s et-up commands coming from either the
digital inputs or via a serial communication bus.
Select preset refe rence 0
[10] selects
preset reference 0.
Select preset refe rence 1 [11] selects
preset reference 1.
*
default setting ()display text []value for use in communication via serial communication port
234
MG.33.B
6.22 - V LT is a registered Danfoss trademark
