FC 300 Design Guide
How to Program
Select preset reference 2 [12 ] – selects
preset reference 2.
Select preset reference 3 [13 ] – selects
preset reference 3.
Select preset reference 4 [14 ] – selects
preset reference 4.
Select preset reference 5 [15 ] – selects
preset reference 5.
Select preset reference 6 [16 ] – selects
preset reference 6.
Select preset reference 7 [17] - selects preset
reference 7. If the active preset reference is
changed, it will merge with other preset reference
commands coming from either the digital inputs
or via a s erial c ommunication bus.
Select ramp 1 [18] - selects ramp 1.
Select ramp 2 [19] - selects ramp 2.
Select ramp 3 [20] - selects ramp 3.
Select ramp 4 [21] - selects ramp 4.
Run [22] - issues a star t command to the
adjustable frequency drive.
Run revers e [23] - issues a start revers e command
to the adjustable frequen cy drive.
Stop [24] - issues a stop command to the
adjustable frequency drive.
Qstop [25] - issues a quick stop command to
the adjusta ble frequency drive.
Dcstop [26]-issuesaDCstopcommandto
the adjusta ble frequency drive.
Coast [27] - the adjustable frequency drive
coasts immediately. All stop commands including
the coast command stop the SLC.
Freeze output [28] - freezes the o utput frequency
of the adjustable freque n cy drive.
Start timer 0 [29] - starts timer 0, see par.
13-20 for further d escription.
Start timer 1 [30] - starts timer 1, see par.
13-20 for further d escription.
Start timer 2 [31] - starts timer 2, see par.
13-20 for further d escription.
Set digital output A l ow [32] - any output with
‘digital output 1’ selected is low (off).
Set digital output B low [33] - any output with
‘digital output 2’ selected is low (off).
Set digital output C low [34] - any output with
‘digital output 3’ selected is low (off).
Set digital output D low [35] - any output with
‘digital output 4’ selected is low (off).
Set digital output E l ow [36] - any output with
‘digital output 5’ selected is low (off).
Set digital output F low [3 7] - any output with
‘digital output 6’ selected is low (off).
Set digital output A h igh [38]-anyoutputwith
‘digital output 1’ se lected is high (closed).
Set digital output B high [39] - any output with
‘digital output 2’ se lected is high (closed).
Set digital output C high [40] - any output with
‘digital output 3’ se lected is high (closed).
Set digital output D high [41] - any output wi th
‘digital output 4’ se lected is high (closed).
Set digital output E high [42] - any output with
‘digital output 5’ se lected is high (closed).
Set digital output F high [43] - any output w ith
‘digital output 6’ se lected is high (closed).
Reset Counter A [60] - resets Counter A to zero.
Reset Counter B [61] - resets Counter B to zero.
*
default setting ()display text []value for use in communication via serial communication port
235
MG.33.B
6.22 - V LT is a registered Danfoss trademark
