Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
" 9-** Profibus
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
9-00 Setpoint 0 All setups TRUE 0 Uint16
9-07 Actual Value 0 All setups FALSE 0 Uint16
9-15 PCD write configuration 0 1 setup TRUE - Uint16
9-16 PCD read configuration 0 1 setup T RUE - Uint16
9-18 Node address 126 1 setup TRUE 0 Uint8
9-22 Telegram selection [1] Standard telegram 1 1 setup TRUE - Uint8
9-23 Parameters for signals 0 All setups TRUE - Uint16
9-27 Parameter edit [1 ] Enabled 1 setup FALSE - Uint16
9-28 Process control [1] Enable cyclic master 1 setup FALSE - Uint8
9-53 Profibus Warning Word 0 All setups TRUE 0 V2
9-63 Actual baud rate [255] No baud rate found All setups TRUE - Uint8
9-64 Device Identification 0 All setups TRUE 0 Uint16
9-65 Profile number 0 All setups TRUE 0 Uint8
9-67 Control word 1 0 All setups TRUE 0 V2
9-68 Status word 1 0 All setups TRUE 0 V2
9-71 Save Data Values [0] Off All setups TRUE - Uint8
9-72 Drive Reset [0] No action 1 setup FALSE - Uint8
9-80 Defined parameters (1) 0 All setups FALSE 0 Uint16
9-81 Defined parameters (2) 0 All setups FALSE 0 Uint16
9-82 Defined parameters (3) 0 All setups FALSE 0 Uint16
9-83 Defined parameters (4) 0 All setups FALSE 0 Uint16
9-90 Changed parameters (1) 0 All setups FALSE 0 Uint16
9-91 Changed parameters (2) 0 All setups FALSE 0 Uint16
9-92 Changed parameters (3) 0 All setups FALSE 0 Uint16
9-93 Changed parameters (4) 0 All setups FALSE 0 Uint16
*
default setting ()display text []value for use in communication via serial communication port
263
MG.33.B
6.22 - V LT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
